Zuca Cart Knobs

This is a replacement knob for a Zuca disc golf cart, you can drop in an M12 nut, then glue or insertion fit the back cover and then install.

You will need a 12mm x1.75 (coarse thread) nut, you can also use a lock nut and locknut version of the cover (Cover_Locknut_xxxxx) version.

UPDATE: 2/5/2022

I made one functionality update and one visual update to the housing for version 1.1

The knob was missing a small boss on the top face that lets it ride on the bearing and not the wheel, this meant that you had to add a washer to shim it. This newer version shouldn't require a washer.

I also updated the holes where the cover clips into, they are now blind holes, which helps with the aesthetics a little.
