Terminator Hunter Killer Drone V2

###STL Files for a Y3 Tricopter Terminator Style - suitable for FPV.

Design from the Movie Terminator 3: Rise of the Machines

. Update 8.July 2023 - yt video link ->https://youtu.be/hPnZzsn23Ic . Update 4. May 2022 -missing part: rear_duct_top.stl uploaded .

####Frame and Turbine Design improved, it flys!

Partlist you need to finish:

10mm carbon tube, ~400mm -> cut in parts, connect for the wings and baseplate stability 6mm carbon rod, ~55mm -> rearshaft

T-Motor F7 FC T-Motor ESC Velox V45, V50 or similiar T-Motor F40 IV Pro 1950kV 2x Frontmotors T-Motor F2203,5 2850kv 1x Rearmotor

Hitec HS-5245MG Digital Servo

HQProp Duct-89MMX8 1xL 1xR Prop Frontmotors HQProp Duct-75MMX6 1xR Rearmotor

WS2812B Black Led Strip 60Leds/m or similar, 12cm - Eyes+BottomSpline - optional

RC Receiver + or DJI AirUnit/CaddxVista - optional

Superglue for the tubes AWG 20 Wire to extend the motor wires + heatshrink some servo wire /servo connector for the canopy led eyes some M3 screws 8 m3 spacers for FC/ESC 2 rubber rings for the lipo/canon holder

Print settings PLA+: Layer Height 0.2, Layer Thickness 0.4, 1.2mm Wall thickness, 10% Infill rearservobase -> 25% Infill . Eyes printed on Elegoo Mars 2, with Resione G217 Clear Resin (but this is optional, you can also glue the leds directly behind the slits with hot glue or something) . The front/rearbaseplate can also mill in cfk or cut it out, oldschool of plywood. . . Betaflight 4.2.11, direct dump/preset with my settings & pids in the .txt file

Servo connect to Motor 5/E5 on the T-Motor F7 FC, LEDstripe to LED Output, Sbus from the Receiver to Uart/RX3. Adjust motor 1-3 and the motor direction according to the betaflight tricopter scheme!

####!!!Attention!!!

This T-Motor/Duct/HqProp combination is verrrry loud :-) , comparable to an edf jet. Due to the weight and design, the whole thing is of course not super efficient, but it flies very well. I personally fly The Hunter v2 with two SLS 6s/1100mA (2200mA) up too 5 minutes +, with two SLS 6s/1300 up to 6mins +. It's not comparable to a 5" FPV racer, it shouldn't be. The design and a good flight were my priorities.

The PIDs are set accordingly smooth, I prefer to fly the Hunter V2 in LOS. Of course, FPV is also possible, for the Cam+ Airunit or the Caddx Vista there is space in front. No extra buildplan, this thing is not difficult to build. Look at more pictures on my instagram: vonoben.tv ...or if you have any questions - ask :-)

###Happy Flying!

Video on YT: https://youtu.be/hPnZzsn23Ic
