CR10 CoreXY Conversion V-Slot with Afterburner

Conversion of CR10 V2 to a CoreXY with V-Slot wheels

Mostly inspired by V-King/V-Baby Z-Carriage D/C-Bot

Hardware:

- additional 10x 400mm 2020 V-Slot or T-Slot Profiles (some could be longer with minor changes in design), additional 2x 520mm V-Slot Profiles (for Z-Axis) - all stock profiles are reused w/o shortening - connected all profiles by tapping center holes and connected them with m5 button head screws - Board housing can be equipped with 4010 Fan in the front - Motors are Stock - Stock Heatbed -20Tooth GT2 6mm idlers (2), 20 Toothed 6mm Idlers (6) - For Z-Axis Sync i had some 20T 4mm Idlers - 2x Stock Z Axis (with the rectangular nuts), shrtened to ~500mm - 760mm Closed Belt for the Z Synchronization, 2x 20T Idlers (I had with 4mm Axis, so you could tap for 5mm) - All Profiles, most Screws and Wheels from a CR10 (V2) - Stock power supply, mounted below - Stock V-Slot Wheels (14x ~24mm), additional 7 15x9mm V-Slot Mini Wheels - At least 2x 5x8x1mm Shims per wheel - You need to extend all cables -Stock Z Axis upper bearings - Stock Z Braces are mounted with distance plates as X on the back - Optional MKS mini 12864 , mini 12864 V3Housing - Optional Adapter to mount MKS E3, E3D Board instead of SKR 1.4 - Optional: Roomba HEPA Filter, Carbon palets, Strong 40x40x40 Fan for integrated filter

Features: - Full Build area - 99% of CR10 V2 reused - Compact outer dimensions - Board is for SKR1.4, Display is Stock CR10, MKS1284 Mini or V3 - Board housing with lid, can be opened from the top - X-Carriage fits Afterburner, Stealthburner with CW1 - X-Carriage has integrated BLTOUCH for Stealthburner V6 - All Parts in ABS/PETG, maybe PLA+ for some - Lower Part of Feet can be printed optionally with TPU - Z-Axis Sync - XY Motors in Front, belts and tensioner on the back - Board housing with fan - Optional Filter (Chamber + Left Rear Filter)

I dont remember all sources, if I forgot to add your work as a Remix please give me a notice

There is no BOM or Instructions, you need a lot of fasteners, and you need to connect all profiles (not only with plastic parts)
