Cylindrical and Square Lamp + ESP2886 + Wled

Own and original design of two models of Led lamps (one with a cylindrical shape and the other with a square shape), both were designed in 4 pieces with Fusion 360. The list of components used are as follows:

1-. DC-099 5.5mm x 2.1mm 30V 10A DC Power Jack Socket. 1-. ACEIRMC ESP8266 ESP-12 ESP-12F NodeMcu Mini D1. 1-. BTF-LIGHTING WS2812B RGB 5050SMD Single Addressable 3.3FT 30 Pixels/m 1-. 5V 3A Power Supply

The software used was the WLED:

https://kno.wled.ge/

The wiring diagram is explained within the WLED portal.

Note : In this STL version, I made some improvements by reducing the diameter of the central base where the led strip is placed. This to achieve a greater separation between the LEDs and the diffusion screen.
