Pan and Tilt Gimbal Heewing Ranger T1

Hello, This is a pan and tilt gimbal for the Heewing Ranger T1. At the bottom of the plan is a piece for the servo that attaches there without glue. It holds the servo in place. The servo horns are used to have a good attachment for the servo. One on the bottom and one on the side of the gimbal. You need to trim them into shape a bit. I used two-component glue to attach it. Please make sure you stick them straight. The camera is then attached to the top of the servo with two screws on a holder that's put on the side of the servo with a litte bit of tape that's put on the botton of the camera. It's made for the dji fpv camera. The servos used are the "VOTIK 7350 MG-D Digital Servo Metal gear". Please be aware of the two cables. It can couse freezes in the video feed when they are two near to each other. You can tape one cable to the right side and one cable to the left side. That's working very well. So have fun with this design!
