Orange Pi Zero2 Case with GoPro Mount

I created this design to fill a need for a __printed case for the Orange Pi Zero 2 that can also mount a webcam with your choice of thread or ball attachment__. This Pi enclosure case also incorporates to a GoPro mount so you could use it with similar accessories. It's perfect to place next to, or attach to a 3D Printer and use with OctoPrint.

#### Compatibility & Setup: This Orange Pi case design has been tested with the following. The camera I used is a generic USB-A Camera. * [Orange Pi Zero2](http://www.orangepi.org/html/hardWare/computerAndMicrocontrollers/details/Orange-Pi-Zero-2.html) * [Webcam (Generic brand from Amazon)](https://www.amazon.com.au/dp/B09PD1X7HV?ref=ppx_yo2ov_dt_b_product_details&th=1) - This webcam has a tripod thread attachment and you can also separate the camera from the ball joint, to attach to the ball joint on the case. * USB Splitter Cable for connecting to both Printer and Camera. I used this one Amazon: [Itramax USB Splitter Y Cable 1FT](https://www.amazon.com/Splitter-Extension-Connector-Extender-Charger/dp/B09C5WNNLZ/ref=sr_1_3?crid=3MBLW2S5GWHWK&keywords=Itramax%2BUSB%2BSplitter%2BCable%2B1FT&qid=1683362319&sprefix=%2Caps%2C258&sr=8-3&th=1)

#### Features * Houses Orange Pi Zero2 (No hats) * Snap-fit case in two parts using holes in PCB * Uses compatible GoPro mount. Should also work with [Module Mounting System by HyVye](https://www.thingiverse.com/thing:2194278). * Ventilation front back and sides * Adequate space for [Easycargo Copper Heatsink](https://www.amazon.com.au/dp/B091KMJKY4?psc=1&ref=ppx_yo2ov_dt_b_product_details) 14mm x 12mm x 5mm * High resolution STL mesh

If anyone finds any problems (dimensionally or otherwise) post them up so I can get the fix model.

#### Instructions * **Installing OctoPrint** + If you want to install OctoPrint for 3D Printing with Orange Pi Zero2, then this is an easy-to-follow article (With link to download their Octopi distro): [Orange Pi Zero 2 Kit for OctoPrint Setup and Configuration](https://www.obico.io/docs/user-guides/install-octoprint-orange-pi-zero-2-kit/) * **Printing** + Print the Front + Choose the Back model depending on whether you want a camera attachment, and it if it's a Thread or Ball type, and print + Optional: recommend 5mm Brim + Minimum of 3 Wall Lines * **Assembly** + **IMPORTANT WARNING** Remove any SD card from the Pi to prevent damage to the SD card when placing the Pi in the case + Place the Orange Pi Zero2 in the case back half, being careful to position the Pi ports in the case holes provided + Gently press the Camera housing into the space provided so it just protrudes out-of-the front of the case + Place the front half over the back, gently align PCB holes with the print standoffs. + The camera cable will need to bend to fit inside the case + Gently press the two halves together until they snap-fit together

Credits * [Orange Pi Zero2 by zhikang wang](https://grabcad.com/library/orange-pi-zero-2-2) was used in the mockup render.

> ### : : EXPERIMENTAL DESIGN : : > This model has been designed for a specific use-case, it has not yet undergone extensive testing. __Constructive feedback is appreciated.__
