ImpulseRC Apex DJI O3 camera mount - Max FOV bando edition

[UPDATE 2025-02-28: I added V11 which now has inserts for M3x2mm nuts, providing a perfect grip metal to metal. It is also a sleeker design. No photo of this version but check out the 3D file V11.]

Ultra durable TPU mount for the DJI O3 camera with max FOV up to 55deg tilt on the ImpulseRC Apex. I use it on my bando bashing quad, it survived hard metal and concrete crashes.

FOV is perfect in ultra wide 4:3 and 16:9. Just the props are visible!

Maximal structural integrity! - Mounted on the original camera plates. - Screwed instead of the front standoffs. - One standoff goes at the bottom. - Optional second part with top standoff if you don't use an action camera. Both standoffs are from the Apex frame, bottom is 28mm and top is 10mm.

Printed in TPU 100% infill it is super stiff. Use supports.

I ended up removing my top standoff because I wanted my Action2 back (not shown in pictures).

For assembly the first thing to do is slide in the camera plate, you just need to bend the part a bit.

Check out the view in flight: https://youtu.be/VADZ9A7YNXA
