Raspberrry Pi Camera Module 3 (and Arducam 16MP AF) Case

Сведения о модели

Площадка
Thingiverse
Цена
Бесплатно
Лицензия
CC-BY-SA
Можно печатать, изменять и продавать с указанием автора; переделки — под той же лицензией.
  • 3 Лайки
  • 204 Загрузки
  • 0 Напечатали
  • 5 В подборках
  • 0 Комментарии
  • 1 319 Просмотры

Автор:adamvicknair

Опубликована

Описание

A simple, no-frills, snap-fit camera case designed for the Raspberry Pi Camera Module 3. It probably will fit other cameras with the same form factor and mounting hole spacing. Requires M2 hardware for mounting the camera. I included two separate files, one with blind mounting holes, i.e. they don't go all the way through the case, this would be good for mounting with double-sided foam tape or similar. The other file has through holes, i.e. they extend all the way through the case, that way you can mount it to anything with that has that hole spacing (12.5 mm x 21 mm).

-UPDATE: I made the case smaller so it just fits the camera with no wasted space. I also added a version for the Arducam 16MP Autofocus Camera which has a camera lens hole that is shifted up 1 mm to accommodate that camera.
