Customize Router Flip Plate

Flip Plate - Trimming Machine Router Base Triangular Plate for Slotting and Chamfering

2 style of the plate: - One Thing for big edge/radius - Two-piece - Plate and Base mount. If the mounting holes to the base extend beyond the plate. For small edge/radius

Two ways to construct a triangle: - By the radius of the circumscribed circle (milling radius); - By the length of the side of the triangle.

This Thing can be made manually from plastic, plywood, etc. To do this, select Print_Type = 2D draw in the settings. Then export to PDF file. Print the drawing at 100% scale, stick it on the workpiece and cut out the Thing.

To use laser cutting/engraving, export 2D draw to the CAD file (DWG, SWG, OBJ etc.)
