# Hinged & Lockable Display Mount for Ender 3 V2 Enclosures

This is a **hinged, adjustable, and lockable display mount** designed for relocating the Ender 3 V2 screen outside an enclosure. The mount consists of **three main parts**:

- **Display Holder** - **Hinge Part A** (mounts to the enclosure) - **Hinge Part B** (connects to the display holder)

## 🖨️ Printing Instructions 1. **Hinge Part A** must be printed **vertically** because it has an embedded M4 fiber nut slot. - Pause the print when the nut slot is completed. - Insert the **M4 fiber nut** and resume the print to embed it inside. 2. **Hinge Part B** should also be printed **vertically** for optimal **hinge teeth alignment** and locking function. 3. **Print the Display Holder** in the preferred orientation.

## 🔧 Assembly Instructions 1. **Attach the Display Holder to Hinge Part B** using adhesive. 2. **Join Hinge Parts A and B** using an **M4 × 50mm countersunk bolt**, securing the hinge mechanism. 3. **Mount Hinge Part A** to the enclosure.

## 🛠️ Required Additional Hardware - **1× M4 × 50mm countersunk bolt** - **1× M4 fiber nut**

This design ensures a **secure, adjustable, and easily mountable** screen relocation for your Ender 3 V2 enclosure.
