Ubiquiti Unifi AC Mesh Universal Offset Bracket

This is a wall bracket to allow you to easily mount a Ubiquiti Unifi AC Mesh to a surface. It's designed to hold the radio about 6 inches off of the surface to maximize performance, particularly with MIMO functionality. The bracket is designed to be a tight secure fit on the radio, and hold it firm. It can easily be zip tied to a surface, or you can run screws through the holes. The slots also allow you to easily secure the cabling with zip ties for easy drip loops, and cable routing.

Can mount to poles (perhaps some heat to form it to the curved surface), fences, or a variety of other surfaces. For my application, I used zip tie magnetic mounts to attach magnets to it for mounting to a corrugated metal surface.

I went through several designs adding strengthening elements and ended up with a secure and sturdy bracket that is versatile and easy to use. Enjoy.

If using outdoors, print this part using PETG or some other similar plastic that can withstand the UV. Print upright, no supports should be needed for well tuned printers. (The photo shows an antenna bracket, that is https://www.thingiverse.com/thing:3640531 which is not my design, but I'm using as it works really well to hold the antennas at a good desirable 45 degree angle)
