Yamaha MT-07 / FZ-07 / XSR700 / Tracer 7 – Rear Stunt Pegs / Axle Sliders (M8-M10, Knurled)

3D printable rear stunt pegs / axle sliders designed for the Yamaha MT-07 / FZ-07 platform. Protects the rear axle in case of a crash or drop.

**Threading:** M8 – the axle hole may need to be drilled out to fit. M10 – the axle hole needs to be drilled out to fit.

**Surface:** Knurled outer surface for better grip and a more aggressive look.

**Confirmed compatible (rear):** 2021–2024: MT-07, MT-07 35KW, MT-07 Pure, MT-07 Pure 35KW, MT07, MT07 CA 2017–2020: FZ07, FZ07 ABS, FZ07 ABS CA, FZ07 CA, MT-07 ABS, MT07, MT07 CA 2015–2016: FZ07, FZ07 CA, FZ07 VA, MT-07, MT-07 ABS 2014: MT-07, MT-07 ABS

**Hardware needed:** M8 stainless steel (A2) threaded rod M8 stainless steel hex nuts *or* M10 stainless steel (A2) threaded rod M10 stainless steel hex nuts

**Also available:** M8 / M10 version, smooth / knurled variant, front / rear pegs.

**M8 vs M10:** Originally I designed the sliders for an M10 rod. Drilling the axles out to 9.5mm was pretty easy but getting it to 10mm was a pain. I would choose M8 over M10 if I had to drill the axles out again.

**My Print Settings** Printer: Bambu Lab A1 Material: PETG Infill: 50% (Gyroid or Cubic pattern) Layer Height: 0.16mm High Quality Wall perimeters: 6 Top/Bottom layers: 6-8 ***ATTENTION!!!:*** remember to put in a print pause once the coutout for the hex nut is printed. Then insert the hex nut and continue printing.

**PSA:** These parts have not yet been tested on a real bike. Use at your own risk. I will update this listing if testing results become available.
