Analog Cessna 172 ELT

Analog Cessna 172 ELT (Emergency Locator Transmitter) — Cockpit-Grade Switch

Drop a real-feel ELT switch into your home Cessna 172 sim cockpit. This is a 3-position slide switch (OFF / ARM / ON) with a flush-mount red status LED and a clear acrylic indicator pane — built to match the analog C172 panel layout.

Designed for MobiFlight out of the box: ships with .mfproj files for both MSFS and X-Plane, plus an .mfmc module config. IDC 30 standard wiring keeps it plug-compatible with the rest of the Captain Bob library.

What's included: - STL + 3MF print files (ELT Body, Switch Holder, Rocker, Glass Piece) - MobiFlight project files (MSFS + XP) bundled in MobiFlight.zip - Wiring diagram (PNG) and engineering drawing (PDF) - Front/back panel cutout DXFs for laser-cut backing

Bill of Materials: - 6.5x 3D Printed Parts - 1x Clear Piece, 9.6x11.5mm, 1.6mm thick - 1x LED Red, 5mm - 1x Large 3 Position Slide Switch (a12022200ux0344) - 2x M2 8mm Countersunk Screw - 2x M3 12mm Countersunk Screw - 2x M3 16mm Countersunk Screw - 1x M3 Nut - 1x 150 Ohm Resistor - 1x 3mm Heat Shrink - 1x Black Wire 24 AWG - 1x White Wire 24 AWG

Wiring (IDC 30): Pin 1 GND, Pin 2 5V, remaining pins reserved per IDC standard.

Part of The Cessna 172 Project V3 by Captain Bob Flight Simulation.
