Amplifier case TPA3116

Case for TPA3116 OPENSCAD format - this is alpha version - under development, to be updated. Print without supports.

https://www.aliexpress.com/item/1005004482182177.html

DIMENSIONS: Amplifier module (PCB) 54mm width 79mm length 2mm reserve space for THT component pins

At the edge of the PCB there are 4 mounting holes: the edge of the hole begins 2mm from the edge 4mm diameter of the hole

There are 3 terminals along one of the longer edges: 14mm from the edge first terminal begins (from the left) 34mm from the edge there is the middle terminal 14mm from the opposite edge third terminal begins (from the right) terminal has width and height of 10mm
