Moza SR-P Lite Anti-Tip Wall Brace

Moza SR-P Lite Anti-Tip Wall Brace (Brake Kit Compatible) This wall brace is designed to prevent Moza SR-P Lite pedals from tipping forward under heavy braking. It was specifically designed and tested with the Moza Brake Performance Kit, where the increased brake force can easily lift the pedal base. The brace bypasses the baseboard (skirting board) and transfers the braking load directly into the wall. It also provides enough clearance so the brake pedal never touches the brace throughout its full travel.

Features: - Compatible with Moza SR-P Lite pedals. - Fully compatible with the Moza Brake Performance Kit. - Designed to clear the pedal's full range of motion – the pedals never contact the brace. - Baseboard-offset design allows the load to be transferred directly to the wall. - Simple and rigid one-piece design.

Mounting: - The brace is attached to the pedal base using M4 bolts. - Each brace also includes 2 mm side holes for additional reinforcing screws, increasing the rigidity of the connection under high brake loads. - A recessed pocket for the washer helps distribute the load instead of concentrating it on the printed plastic.

Printing recommendations: - PETG or ABS recommended. - 6–8 perimeters. - 40–50% infill. - Print in the shown orientation for maximum strength.

Why I made this: After installing the Brake Performance Kit, the increased brake force caused my SR-P Lite pedals to tip forward, even while they were resting against the baseboard. I couldn't find a solution that worked around a baseboard while keeping full pedal travel, so I designed this brace myself. Hopefully it helps someone else solve the same problem.
