Description

Note: I did not print this version, if you do please report here and share pictures / make. See the original version for how to assemble it.

This is a 3D printable control box to replace the mainboard enclosure. This enclosure contains:

- A Raspberry Pi 3B for running OctoPrint,

- A BigTreeTech SKR E3 mini main board or the Stock Creality Ender-3 mainboard.

- (optional) A Google AIY Audio Hat with Speaker and microphone,

- 2 LM2596 Step down converter for providing 12V for the lights and 5V for the raspberry Pi,

- 3 5V relay switch modules controlling the printer, the lights and a fan for the raspberry Pi. Cooling

Cooling is done with 2 4010 fan

Sources

Sources

This is totally opensource, with the source file available on GitHub .

Category: 3D Printer Parts

Tags

raspberrypiopenscadender3thingiversecrealityender3
