fAuxLICE keyboard

A 3d print keyboard that u can print with an Ender 3. (220x220). If you don't know anything about custom keyboards, read the full guide for the keyboard. You will need the firmware from the GitHub repo to flash.

Components

Required components

- 1x Arduino Pro Micro - 64× switches of your choice - 108-key keycap set - 64× diodes - Wires - 14× M3×16 countersunk screws - 2× M3×12 countersunk screws Optional components

- 4× reinforceplate-mounted Costar stabilizers - 1× M3×8 countersunk screw - 1× M3×10 countersunk screw - 1× M3×12 countersunk screw - 1× M3×16 countersunk screw - 1× M3×20 countersunk screw

The optional components are for reinforcing the top halves. They're not required. A proper glue-up would probably be enough for the two halves.
