Kitchen Cabinet Hanging Shelf, Spice, Medicine

I designed this shelf to add some additional storage space to our kitchen cabinets, for smaller spice and medicine bottles. I wanted something that didn't require drilling holes or double sided tape. The shelf has hooks that attach to the shelf above and are held in place. Works for shelves with 0.75" thickness. I had about 10.5" of usable depth in my cabinets, so the 5.25" version allows for 2 shelves to fit the full space. The 9.50" version is about the largest that I can fit on my Prusa MK3, without quite using 100% of the build plate.

1/26/20 - Added some additional sizes, 6.5", 7.5" and 8.5" widths, just need to check the location of the existing shelf clips to make sure it will fit.

Print instructions

Category: Organization Print Settings

Printer Brand: Prusa

Printer: I3 MK3S

Rafts: No

Supports: No

Resolution: 0.3

Infill: 25%

Filament: Prusament PLA Galaxy Black

Notes:

I set perimeters to 5 so that the thin section were solid.
