Accelerometer Mount for ADXL345 on Ender-3 S1 Pro

Model details

Platform
Printables
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
Formats
STL
  • 37 Likes
  • 560 Downloads
  • 4 Makes
  • 7 Comments
  • 3 922 Views

Author:norfanos

Published

Download on Printables

Description

Modeled for Ender-3 S1 Pro using right-hand stock fan mounts. Reuses stock short M3 from shroud to mount the sensor, mated with a M3 x 4mm brass insert. Requires M3 x 8mm, possibly 6mm, to replace the repurposed shroud screws.

Amazon US link for the sensor Diitao GY-291 ADXL345: https://a.co/9movHVn

Printed at 30% honeycomb infill in PETG. Designed on Fusion360.

Tags

ender3s13axisaccelerometerender3s1pro
