Bambu Lab X1C Chamber Heater/Bauraumheizung

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
F3DSTL3MFSTEP
  • 39 Likes
  • 170 Downloads
  • 1 Makes
  • 2 Comments
  • 4 883 Views

This model on other platforms

Author:Tinker.Fun

Published

Download on Printables

Description

I have built a chamber heater for the X1C. There are also the Fusion 360 projects files for download. You can modify the parts für your need. Please check my YouTube Video for more insights.

Current connection diagram. The fan of the chamber heater is always on when the 3D printer is switched on. You can also solve it otherwise if you want. The Meross thermostat receives power when the 3D printer is switched on and can then optionally heat.

AC Board: https://wiki.bambulab.com/en/x1/maintenance/replace-ac-board

Power Supply: https://wiki.bambulab.com/en/x1/maintenance/replace-power-module

Über eure Unterstützung würde ich mich sehr freuen: https://www.paypal.com/paypalme/tinkerfun

I would be very happy about your support: : https://www.paypal.com/paypalme/tinkerfun

Parts:

- 230V Controller Meross Smart Thermostat: https://amzn.to/4bXRzP4 - Chamber Heater: Cirrus 40/2 - www.schaltschrankheizer.de - 370090-01 Heater: 230W/230V Fan: DC 24V

Tags

heaterchamberx1chamberheaterbambubambulabx1cp1sbauraumbauraumheizung
