Bltouch mount for Eryone Thinker SE

My own bltouch mount I designed, as I didn't find any that would properly fit my printer (how does that happen I have no idea). This is technically a remix as I took of the basic dimensions, but at the end I designed everything from scratch (bigger cables hole, properly spaced screw holes etc.)

It's a bit finicky to install as you need to take down the hot end assembly and put small nuts in it to lock the mount in place, but apart from that it works nicely.

After reading a bit, I found out that the bottom part of the bltouch (without counting the plastic rod) has to be 8.3mm higher than the lowest part of the hot end nozzle, I used 3 washers in order to lower it at the correct height.

If you have any issues with the mount lemme know

Print Settings

Printer:

Eryone Thinker SE

Rafts:

No

Supports:

No

Resolution:

0.25

Infill:

100%

Filament:

eSun PLA+ Light Green

Notes:

I printed the adapter at 100% infill, but even 5% should be enough as the bltouch is never subject to external forces
