5.5-Inch Irrigation Ring With 0.25-Inch Tube Inlet

This is a 5.5-inch diameter irrigation ring designed to be used with 0.25-inch ID Tubing. Use a small ball valve to adjust the flow rate of the water through the ring. This works perfectly with my 2-Liter Soda Bottle To 0.25-Inch ID Tube Adapters and 2-Liter Soda Bottle Clamp Mount

A T-Stake Hold Down .stl file is included and should be used to secure the irrigation ring to the soil.

Tested to work with the following tubing:

- JoyTube ¼" ID Silicone Tubing - https://amzn.to/379qGuq - Rollerflex ¼" ID Crystal Clear Vinyl Tubing - https://amzn.to/3uOudX9 - Outfandia ¼" ID Irrigation Tubing - https://amzn.to/3iWKAeP - Feelers Drip Irrigation ¼" OD Switch Valve - https://amzn.to/3LD5I69 *Note: As these models need to be printed watertight, and quite sturdy, I recommend printing with 6 perimeters, and 5-6 top and bottom layers.

*Note: Add a support enforcer in Prusa Slicer to support the tube inlet nub as pictured in the Support Enforcer Image located in the image gallery.

*Note: This post contains Amazon Affiliate links that support The Makers Workbench via a small commission from any sales they help generate.

Design File Included: .stl .f3d, step, .skp and obj files.

Follow The Makers Workbench on:

- Instagram - YouTube - Rumble - Locals - GAB - Gettr - Odysee - Paypal.me - Patreon - TheMakersWorkbench.com I have only tested this model using the default 0.20mm 100mm/s preset in Prusa Slic3r 2.3.3 with the following amendments made.

Print Settings

- 6-perimeters - 5-top layers - 5-bottom layers - 20% infill - Rectilinear Infill - Monotonic Top and Bottom Pattern - Detect Bridging Perimeters - True Support Settings - Set Support for Enforcers Only

- Contact Z Distance - 0.2mm - Pattern Spacing - 2mm - Pattern Angle - 0-degrees - Interface Layers - 2 - Interface Pattern Spacing - 0.2mm *Note: Add a support enforcer in Prusa Slicer to support the tube inlet nub as pictured in the Support Enforcer Image located in the image gallery.

PLA Used: Polymaker Polyterra Eco-Friendly PLA - https://amzn.to/3qPYtzV
