m8 25mm Bolt

Customized version of https://www.thingiverse.com/thing:193647

Created with Customizer! https://www.thingiverse.com/apps/customizer/run?thing_id=193647

Instructions

Using the following options:

type = bolt

head_type = hex

drive_type = socket

head_diameter = 12

head_height = 5

drive_diameter = 8

slot_width = 1

slot_depth = 2

texture = exclude

thread_outer_diameter = 8

thread_step = 1.25

step_shape_degrees = 45

thread_length = 25

countersink = 2

non_thread_length = 0

non_thread_diameter = 0

nut_type = normal

nut_diameter = 12

nut_height = 6

nut_thread_outer_diameter = 9

nut_thread_step = 1.25

nut_step_shape_degrees = 45

wing_ratio = 1

inner_diameter = 8

outer_diameter = 14

thickness = 2

facets = 6

socket_facets = 6

socket_depth = 3.5

resolution = 0.5

Category: Parts
