Lowrider CNC - X Axis Cable Management

This is a simple device for keeping your x-axis cable off the table on a Lowrider CNC. The weight on the end clamps onto the cable and the bearing guides the cable. Pretty simple idea but works great.

Weighted Box - Needs M3 x 25 screw and M3 nuts (x4)

Bearing Guide - 608 Bearing, M6 x 30 Bolt, M6 Nut

The bearing guide attaches using the bolt that holds on the inline wheel on the Y-Plate.

Print instructions

Printed without supports. Doesn't need a lot of strength. I did 2 parameters and 20% infill.

Spacer is for M6 bolt going through the bearing.

Spacer M5 is if you want to use an M5 bolt instead of M6.
