NAS ITX PC Case with stackable expansions [MODCASE MASS]

The Modular Attached Storage Stack ( link ) is a compact 3D printed NAS enclosure with expandable bays support up to 8x 3.5" + 3x 2.5" drives.

👉For the premium version of MASS with additional features, please see MASS Premium Page here .

Features

- Minimal Part count. Maximum Strength. Sturdy and simple assembly with 1 screw type for all

- Expandable Drive Support Stackable Modules for up to 8x 3.5” + 3x 2.5” drives

- Fully 3D Printable 210x210mm Print volume, optimized for FDM

- Powerful Airflow Quiet vertical airflow with 3x 140mm fans

- Customizable Add a touch screen and other optional features

The Premium version of MASS adds the following:

- PCIE Slot Support

- 5 Drives per Caddy

- Capacity for Up to 13 Drives

- Handles

- Dual 2.5” to 3.5" Drive Adapters

- FlexATX PSU support

- Addon Fan Modules

- Supports development of more MODCASE designs!

Specs:

MASS Premium

MASS Free

Drive Bays

Up to 10x3.5” + 3x2.5"

4x3.5”+ 3x2.5"

PCI-E Slot

1 Slot Low-Profile

NA

PSU

SFX, SFX-L, FlexATX

SFX, SFX-L

Fans

3x 140mm or 120mm

3x 140mm or 120mm

CPU Cooler

66mm tall

55mm tall

Printer Requirements

Min. Bed 210x210 240°C Nozzle

Min. Bed 200x200 240°C Nozzle

Core Size (APU)

210x199x162mm 6.7L
