Meshify C Top Cover for Radiator

If you mount a radiator on your Fractal Design Meshify C and the computer is mounted under the desk, trapped heat might be sucked in from the top. That is why i made this cover.

Upside is, that you don't need the mesh filter anymore if you use a push configuration to blow out hot air on the top, since there is constant airflow no dust gets sucked back in.

On regular usage the temperature is slightly better than before - but i originally intended this to be just aesthetic ;)

Printing

- Fits in one piece on a 250x250 printbed diagonally - Recommend a temperature stable filament, PETG or ASA/ABS - recommended print settings are included in the 3mf file for Bambu Studio / Orca Slicer

Assembly

Remove the magnetic dust cover and just place the piece ontop - it is a gravity fit, not a snap fit. it is intentionally 0,2 mm lower then the height of the indent in the top so it does not get knocked accidentially

to remove it just “pry” it out with some lever from one of the exposed hex pieces
