3d Printed Hitbox

Hardware Used:

*6x* M3x8 Socket Head Screws (PCB Mount) *3x* M3x6 Socket Head Screws (Key Plate) *8x* M3x18 **Flat** Head Screws (Bottom Cover) *17x* M3nS Thin Square Nuts

*9x* [Sanwa OBS-24 24mm Buttons](https://focusattack.com/sanwa-obsf-24mm-pushbutton-white/) *1x* [Sanwa OBSF-30 30mm Button](https://focusattack.com/sanwa-obsf-30mm-pushbuttons-white/) *1x* [Neutrik NAUSB-W A/B USB Feed Through](https://focusattack.com/neutrik-nausb-w-a-b-usb-feed-through-silver/) *5x* [Cherry MX Red Switches](https://novelkeys.com/collections/switches/products/cherry-switches?variant=40599113007271)

*1x* [IST PRE-INSTALLED BROOK PS3/PS4/PC FIGHT BOARD PCB KIT](https://support.focusattack.com/hc/en-us/articles/360016015671-IST-Pre-Installed-Brook-PS3-PS4-PC-Fight-Board-PCB-Kit-Firmware-and-Connection-Diagram) (**I think this has been discontinued**)

A custom PCB Plate can be made to mount a different pcb. The dimensions are listed in the picture posted below.

I soldered spade connector wires onto the cherry mx switches to easily connect them through the the key plate.
