The plates here differ mainly in shape and purpose: some are plain sheets with a slot or a hole pattern, others are adapter plates that join two different mounts, and a few are brackets or hinges that hold a plate at an angle. Pins, plugs and shaft covers solve a different problem, closing an opening or centring a part, while caps and washers sit under a screw head. Push-pin grids and similar flat tiles are a separate group, useful when you want to test how a thin printed sheet behaves before committing to a larger plate.

Before printing, measure the original part: overall length and width, thickness, the width of the blade slot, the spacing and diameter of the mounting holes, and the position of any adjustment slots. On the model page, look at the number of separate parts, whether supports are needed, and the material, layer height and wall count the author lists. Photos of real prints are more informative than renders, especially for thin plates that can warp. If the plate carries the saw body, think about how the load runs through the layers and choose an orientation that puts stress along the print, not between layers.

Search terms vary, so try several: sole plate, base plate, shoe, guide plate, adapter plate, mounting bracket, and the saw model or blade size you work with. Related topics are worth a look too, such as guide rails, dust ports, depth stops and jigs built around a saw. If a result is close but not exact, check whether the author published a parametric version or a set of sizes, since changing hole spacing is often easier than modelling a plate from scratch.
