SOVOL SV08 HEAD Filament Cutting

Modification of this great project . Removed the lever system. Direct action on the blade holder. Holding the knife holder and returning it to its original state using magnets. The blade is easily removed for replacement. 3 magnets 6x3mm N52 are used, they must be positioned so that in the pressed position the magnets are repelled, in the released position they are attracted. The lid is taken from this project and modified for this mod.

Macros

[gcode_macro FILAMENT_CUTTING] gcode: G92 E0 G1 Y0 F5000 G1 X10 F5000 G1 X2 Y0 F1000 G1 X10 Y0 F1000 G1 E-10 F2000
