Low height din rail mount for LRS-200, RS-25, raspberry pi(3or4 and zero 2), and BTT octopus

Площадка: Printables
Цена: Бесплатно
Лицензия: CC0; Общественное достояние: можно печатать, изменять и продавать без указания автора.
Форматы: STL

268 Лайки
2 020 Загрузки
16 Напечатали
23 Комментарии
8 312 Просмотры

Автор:Frogree

Опубликована 07.01.2023

Скачать на

Printables

Описание

LRS-200 : M4x5-8mm BHCS, SHCS x4 *8mm bolts may too long, be careful. RS-25 : M3x5-8mm BHCS, SHCS x 2 *8mm bolts may too long, be careful.

raspberrypi : M2.5x5mm or longer BHCS/SHCS x4, designed for considering self fixation without using nut, also possible to use raspberrypi cases *compatible with pi4, pi3

Octopus : M3x5mm or longer BHCS/SHCS x4, designed for considering self fixation without using nut *also compatible with pro

raspberrypi zero : M2.5x5mm or longer BHCS/SHCS x4, designed for considering self fixation without using nut, it can be access via bottom surface for using stacking accessory
