Planetary designs appear in both single-stage and stacked versions, where several stages are chained to reach a higher reduction. RC-oriented entries tend to be complete transmission housings with mounts and skid plates that fit a specific chassis family, while standalone gear sets are just the toothed parts. Bevel and right-angle units change the direction of the drive, which matters when the motor has to sit along the chassis rather than across it.

Before printing, look at the reduction ratio and what it implies for torque and speed, then check the module or tooth profile the author specifies, since mixing profiles from two sources rarely works. Read the part list: how many pieces the assembly has, whether bearings, shafts or screws are required, and whether the author printed it in one piece or in sections. Layer height, wall count and material choice affect how well teeth mesh, so the settings on the model page are worth following closely, and photos of finished prints show how the parts actually fit together.

If the results feel narrow, try related wording: transmission, transfer case, speed reducer, worm drive, cycloidal drive, or the ratio you need, such as 1:10 or 1:36. Searching by the chassis or scale you are building, or by the shaft diameter and bearing size, often narrows the list faster than the word gearbox alone. Combining a gearbox term with mount, housing or adapter brings up the surrounding parts rather than the gears themselves.
